Description
80° beam angle.
Halogen option available.
Bezel designs also available in other ranges.
If you require bespoke bezels or any alterations to existing designs please contact us.
Coloured LEDs available.
LED Colour: 2,700K
LED Power – 5 Watt, 360lm, min 90CRI
Rated Current – 350mA
Forward Voltage – 12 V DC
(constant current drivers required)
LED Colour: 2,700K
LED Power – 10 Watt, 660lm, min 90CRI
Rated Current – 700mA
Forward Voltage – 12 V DC
(constant current drivers required)
LED Colour: 3,000K
LED Power – 5 Watt, 401lm, min 90CRI
Rated Current 350mA
Forward Voltage – 12 V DC
(constant current drivers required)
LED Colour: 3,000K
LED Power – 10 Watt, 736lm, min 90CRI
Rated Current – 700mA
Forward Voltage – 12 V DC
(constant current drivers required)
LED Colour: 5,000K
LED Power – 5 Watt, 485lm, min 80CRI
Rated Current 350mA
Forward Voltage – 12 V DC
(constant current drivers required)
LED Colour: 5,000K
LED Power – 10 Watt, 920lm, min 80CRI
Rated Current 700mA
Forward Voltage – 12 V DC
(constant current drivers required)
Cable length is 125mm as standard, please enquire for custom lengths.
Hole cut out: 64mm
Fixing method: Three M4 counter sunk screws on a 82mm PCD (not supplied).
Supplied with two gaskets.
Please note this product requires a LED driver. Driver not included but these are available to order.
